Open frame type
Product Model: KDF2500X/XE
Open-frame type diesel generator, 2KW, low oil shutdown, recoil or electric start optional.
 |
|
Model |
KDF2500X/XE |
|
Rated frequency (Hz) |
50 |
60 |
|
Rated voltage (V) |
220, 230, 240, 110/220, 115/230, 120/240 |
|
Rated output power (KW) |
1.8 |
2 |
|
Max output power (KW) |
2 |
2.2 |
|
Rated rotation speed (rpm) |
3000 |
3600 |
|
Power factor cosφ |
1 |
|
Phase number |
Single |
|
Pole number |
2 |
|
Excitation transistorized |
Self-excitation, brushless |
|
ATS type |
Without ATS, optional |
|
Structure type |
Open-frame |
|
Fuel consumption (g/KW.h) |
370 |
|
Fuel tank capacity (L) |
12.5 |
|
Continuous running time (hr)(at rated power) |
22 |
|
Noise level (dBA@7m) (zero load ~ full load) |
72-77 |
|
Net weight (kg) |
X: 53 |
XE: 60 |
|
Overall dimension (mm)(L×W×H) |
610×460×520 |
|
Starting system |
X: recoil starter; XE: electric starter |
|
Fuel type |
0＃ (summer), -10＃ (winter), -35＃ (chill cold) diesel oil |
|
Lube |
SAE10W30 (above CC grade) |
|
Engine model |
X: KD170F |
|
XE: KD170FE |
|
Engine type |
1-cylinder, 4-stroke, air-cooled, verical, diesel engine |
|
Bore×stroke (mm) |
70×55 |
|
Displacement (cm3) |
0.211 |
|
Compression ratio |
20:01 |
|
Rated power (KW/rpm) |
2.5/3000 |
2.8/3600 |
|
Rotation direction (view from the flywheel) |
Clockwise |
Product Model: KDF4000X/XE
Open-frame type diesel generator, 3KW, low oil shutdown, recoil or electric start optional. |
|
Model |
KDF4000X/XE |
KDF4000X-3/XE-3 |
|
Rated frequency (Hz) |
50 |
60 |
50 |
60 |
|
Rated voltage (V) |
220, 230, 240, 110/220, 115/230, 120/240 |
380/220, 400/230, 420/240 |
|
Rated output power (KW) |
2.6 |
3 |
2.6 |
3 |
|
Max output power (KW) |
3 |
3.3 |
3 |
3.3 |
|
Rated rotation speed (rpm) |
3000 |
3600 |
3000 |
3600 |
|
Power factor cosφ |
1 |
0.8 (lag) |
|
Phase number |
Single |
Three |
|
Pole number |
2 |
|
Excitation transistorized |
Self-excitation, brushless |
Self-excitation, constant voltage (AVR) |
|
ATS type |
Without ATS, optional |
|
Structure type |
Open-frame |
|
Fuel consumption (g/KW.h) |
370 |
370 |
|
Fuel tank capacity (L) |
12.5 |
|
Continuous running time (hr)(at rated power) |
14 |
14 |
|
Noise level (dBA@7m) (zero load ~ full load) |
72-77 |
72-77 |
|
Net weight (kg) |
X: 65 |
XE: 70 |
X: 65 |
XE-3: 70 |
|
Overall dimension (mm)(L×W×H) |
705×460×535 |
705×460×535 |
|
Starting system |
X: recoil starter; XE: electric starter |
|
Fuel type |
0＃ (summer), -10＃ (winter), -35＃ (chill cold) diesel oil |
|
Lube |
SAE10W30 (above CC grade) |
SAE10W30 (above CC grade) |
|
Engine model |
X: KD178F |
X-3: KD178F |
|
XE: KD178FE |
XE-3: KD178FE |
|
Engine type |
1-cylinder, 4-stroke, air-cooled, verical, diesel engine |
|
Bore×stroke (mm) |
78×62 |
78×62 |
|
Displacement (cm3) |
0.296 |
0.296 |
|
Compression ratio |
20:01 |
20:01 |
|
Rated power (KW/rpm) |
3.7/3000 |
4.0/3600 |
3.7/3000 |
4.0/3600 |
|
Rotation direction (view from the flywheel) |
Clockwise |
Product Model: KDF6500X/XE
Open-frame type diesel generator, 5KW, low oil shutdown, recoil or electric start optional. |
|
Model |
KDF6500X/XE |
KDF6500AX/AXE |
KDF6500X-3/XE-3 |
KDF6500AX-3/AXE-3 |
|
Rated frequency (Hz) |
50 |
60 |
60 |
50 |
60 |
60 |
|
Rated voltage (V) |
220, 230, 240, 110/220, 115/230, 120/240 |
380/220, 400/230, 420/240 |
|
Rated output power (KW) |
4.2 |
4.5 |
4.5 |
4.2 |
4.5 |
4.5 |
|
Max output power (KW) |
4.5 |
5 |
5 |
4.5 |
5 |
5 |
|
Rated rotation speed (rpm) |
3000 |
3600 |
3600 |
3000 |
3600 |
3600 |
|
Power factor cosφ |
1 |
0.8 (lag) |
|
Phase number |
Single |
Three |
|
Pole number |
2 |
|
Excitation transistorized |
Self-excitation, brushless |
Self-excitation, constant voltage (AVR) |
|
ATS type |
Without ATS, optional |
|
Structure type |
Open-frame |
|
Fuel consumption (g/KW.h) |
360 |
340 |
360 |
340 |
|
Fuel tank capacity (L) |
12.5 |
|
Continuous running time (hr)(at rated power) |
7.5 |
8 |
7.5 |
8 |
|
Noise level (dBA@7m) (zero load ~ full load) |
75-79 |
75-79 |
|
Net weight (kg) |
X: 95 |
XE: 100 |
X: 95 |
XE: 100 |
X: 95 |
XE-3: 100 |
X: 95 |
XE-3: 100 |
|
Overall dimension (mm)(L×W×H) |
735×485×670 |
|
Starting system |
X: recoil starter; XE: electric starter |
|
Fuel type |
0＃ (summer), -10＃ (winter), -35＃ (chill cold) diesel oil |
|
Lube |
SAE10W30 (above CC grade) |
CD or better than CD |
SAE10W30 (above CC grade) |
CD or better than CD |
|
Engine model |
X: KD186F |
X-3: KD186F |
|
XE: KD186FE |
XE-3: KD186FE |
|
Engine type |
1-cylinder, 4-stroke, air-cooled, verical, diesel engine |
|
Bore×stroke (mm) |
86×70 |
86×72 |
86×70 |
86×72 |
|
Displacement (cm3) |
0.406 |
0.418 |
0.406 |
0.418 |
|
Compression ratio |
19:01 |
19:01 |
19:1 |
|
Rated power (KW/rpm) |
5.7/3000 |
6.3/3600 |
6.3/3600 |
5.7/3000 |
6.3/3600 |
6.3/3600 |
|
Rotation direction (view from the flywheel) |
Clockwise | |
