Model |
G650CL |
G950CL |
G2000CL |
G25000CL |
G35000CL |
|
Alternator |
|
Alternator type |
Single-phase, synchronous alternator |
|
Frequence |
50Hz 60Hz |
|
Rated AC output |
450W 550W |
650W 800W |
1.6kW 1.8kW |
2.0kW 2.2kW |
3.0kW 3.3kW |
|
Max. AC output |
550W 650W |
800W 950W |
1.8kW 2.0kW |
2.2kW 2.5kW |
3.3kW 3.6kW |
|
Voltage |
110V,120V,220V,230V,240V.(For option) |
110V,120V,220V,230V,240V,220/110V,240/120V.(For option) |
|
DC output |
12V*8.3A(For option) |
|
Power factor |
1 |
|
Excitation system |
Self-excitation |
|
Engine |
|
|
|
|
|
|
Mode |
G60 |
G160 |
G240 |
|
Type |
Single-cylinder, vertical, 2-storke, air-coolied, gasoline engine. |
Single-cylinder, 25°-inclined, 4-storke, air-cooled,OHV, gasoline engine |
|
Displacement |
63cc. |
63cc. |
163cc. |
163cc. |
242cc. |
|
Bore |
45mm |
45mm |
68mm |
68mm |
73mm |
|
Stroke |
40mm |
40mm |
45mm |
45mm |
58mm |
|
Speed |
3000RPM 3600RPM |
|
Compression ratio |
|
8.5:1 |
8.5:1 |
8.2:1 |
|
Continuous output |
1.35hp 1.5hp |
1.35hp 1.5hp |
4.1hp 4.5hp |
4.1hp 4.5hp |
6.0hp 6.5hp |
|
Max. output |
1.5hp 1.65hp |
1.5hp 1.65hp |
4.5hp 5.0hp |
4.5hp 5.0hp |
6.5hp 7.0hp |
|
Starting system |
Recoil starter |
Recoil starter |
Recoil starter |
|
Cooling system |
Forced air |
|
Governor system |
Centrifugal weight system |
|
|
Ignition system |
|
TCI(Transistorrized pointless) |
|
Oil alarm |
|
Built-in |
|
Fuel |
Unleaded petrol |
|
Fuel tank capacity |
7.8L |
7.8L |
15L |
15Lt. |
25L |
|
Gasoline and oil mixing ratio |
50:01:00 |
50:01:00 |
|
|
|
|
Lub. Oil capacity |
|
|
0.6L |
0.6Lt. |
1.1L |
|
Continuous working time |
12h |
|
15h |
12 |
13h |
|
Noice level |
64dB(A)at7mts |
64dB(A)at7mts |
67dB(A)at7mts |
67dB(A)at7mts |
69dB(A)at7mts |
|
Package dimensions and weight |
|
L*W*H(mm) |
390*350*355 |
390*350*355 |
620*460*480 |
620*460*480 |
710*520*607 |
|
Dry weight |
21kg |
21kg |
41kg |
43kg |
71kg |
|
Model |
G4000CL |
G5000CL |
G5000CLE |
G6500CL |
G6500CLE |
|
ALTERNATOR |
|
|
Alternator type |
Single-phase, synchronous alternator |
|
Frequence |
50Hz 60Hz |
|
Rated AC output |
3.5kW 3.7kW |
4.2kW 4.5kW |
4.2kW 4.5kW |
5.5kW 6.0kW |
5.5kW 6.0kW |
|
Max. AC output |
3.8kW 4.0kW |
4.5kW 5.0kW |
4.5kW 5.0kW |
6.0kW 6.5kW |
6.0kW 6.5kW |
|
Voltage |
110V,120V,220V,230V,240V,220/110V,240/120V.(For option) |
|
DC output |
12V*8.3A |
|
Power factor |
1.0 |
|
Excitation system |
Self-excitation |
| Engine |
|
Mode |
G270 |
G340 |
G340E |
G390 |
G390E |
|
Type |
Single-cylinder, 25°-inclined, 4-storke, air-cooled,OHV, gasoline engine |
|
Displacement |
270cc. |
337cc. |
337cc. |
389cc. |
390cc. |
|
Bore |
77mm |
82mm |
82mm |
86mm |
86mm |
|
Stoke |
58mm |
64mm |
64mm |
64mm |
64mm |
|
Compression ratio |
8.2:1 |
8.0:1 |
8.0:1 |
|
|
|
Speed |
3000RPM 3600RPM |
|
Continuous output |
7.3hp 8.0hp |
8.2hp 9.0hp |
8.2hp 9.0hp |
9.5hp 10.5hp |
9.5hp 10.5hp |
|
Max. output |
8.0hp 8.8hp |
9.0hp 10.0hp |
9.0hp 10.0hp |
10.5hp 12.0hp |
10.5hp 12.0hp |
|
Starting system |
Recoil starter |
Recoil starter |
Recoil/Electric starter |
Recoil starter |
Recoil/Electric starter |
|
Cooling system |
Forced air |
|
Ignition system |
TCI(Transistorrized pointless) |
|
Oil alarm |
Built-in |
|
Fuel |
Unleaded petrol |
|
Fuel tank capacity |
25Lt, |
25L |
25L |
25L |
25L |
|
Lub. Oil capacity |
1.1Lt, |
1.4L |
1.4L |
1.4L |
1.4L |
|
Continuous working time |
11h |
10h |
10h |
8h |
8h |
|
Noice level |
70dB(A)at7 mts |
71dB(A)at 4 mts |
71dB(A)at 4 mts |
72dB(A)at 4 mts |
72dB(A)at 4 mts |
| Package dimensions and weight |
|
L*W*H(mm) |
710*520*607 |
750*520*607 |
750*580*607 |
750*520*607 |
750*580*607 |
|
Dry weight |
73kg |
83kg |
86kg |
88kg |
91kg | |
