Model |
KDF6500WE |
KDF6500AWE |
|
Rated frequency (Hz) |
50 |
60 |
60 |
|
Rated voltage (V) |
230 |
240 |
240 |
|
Rated current (A) |
8.7 |
9.2 |
9.2 |
|
Rated output power (KW) |
4.2 |
4.5 |
4.5 |
|
Rated rotation speed (rpm) |
3000 |
3600 |
3600 |
|
Welding voltage without load (V) |
55-65 |
|
Rated current (A) |
160 |
|
Work voltage (V) |
26 |
|
Current regulation range (A) |
50-180 |
|
Welding load continuous ratio |
60% |
|
Power factor cosφ |
1 |
|
Phase number |
Single phase |
|
Noise level dB(A)@7m (zero load-full load) |
74-79 |
|
Net weight [kg(lbs)] |
154 (338) |
|
Overall dimension [mm(in)](L×W×H) |
775×485×580 (30.51×19.09×22.83) |
|
Structure model |
Open-frame |
|
Engine model |
KD186FE |
KD186FAE |
|
Engine type |
1-cyliner, 4-stroke, air-coolde, vertical, diesel engine |
|
Displacement [cm3(Cu-in)] |
406 (24.78) |
|
|
Compression ratio |
19:01 |
|
Reted power [KW(Hp)/rpm] |
6.3 (8.6)/3600 |
|
Rated rotation speed (rpm) |
3000/3600 |
3600 |
|
T.C.L. |
No |
|
Spark plug |
12V electric starter |
|
Starting system |
Electric starting |
|
Rotation direction (view from flywheel) |
Clockwise |
|
Fuel type |
0＃ (summer), -10＃ (winter) diesel oil |
|
Lube |
SAE10W30 (above CC grade) |
CD or bettet than CD |
|
Low oil presssure alarm system |
With |
